| Laser Type | CO2 |
| Wavelength | 10,600nm |
| Laser Emission Mode | Pulsed |
| Output Power | 60 watts (maximum peak) |
| Laser Beam Energy | Variable from 1 - 80 mJ |
| Pulse Repetition Rate | Up to 16.7 kHz |
| Pulse Duration | 20 - 3000 μsec |
| Power Stability | ± 1.5 watts (±5%) |
| Mode Quality (M²) | < 1.2 |
| Beam Size | Ø 1.8 ± 0.5 mm |
| Beam Divergence | 7.5 ± 0.5 mrad (full angle) |
| Polarization | > 100:1 linear (orthogonal to mounting pads) |
| Maximum Scan Area | 10 mm diameter |
| Aiming Laser | 5 mW, 650 nm (red) diode laser |
| Articulated Arm | Lightweight, aluminum fiber, 7-joint, pneumatically balanced Treatment radius at full arm extension: 85 cm (33.5") Horizontal rotation: 360° |
| Lens Assemblies | 150 μm spot size 120 μm spot size (optional) |
| Handpiece | Multi-use or surgical hand piece |
| User Interface | 10.4" high-resolution |
| Laser Emission Control | Footswitch |
| Laser Emission Indicators | Solid amber LED in Standby and Ready modes Flashing red LED during laser emission |
| Electrical Requirements | 100 - 240 VAC self-sensing 50/60 Hz, 7.1 A, single phase |
| Dimensions | 40 cm x 44 cm x 177 cm (15.75" x 17.3" x 70") |
| Weight | 26 kg (58 lbs) |
Operating Modes
| Mode | Energy Settings | Fractional Coverage | Estimated Ablation Depth |
| CO2RE Light | 18 - 74.5 mJ | 30 - 50% | 20 - 40 μm |
| CO2RE Mid | 45 - 257 mJ | 20 - 40% | 100 - 200 μm |
| CO2RE Deep | 30 - 70 mJ | 1 - 5% | 500 - 750 μm |
| CO2RE Fusion | 45 - 128 mJ 30 - 70 mJ |
20 - 40% | 100 - 200 μm & 500 - 750 μm |
| Classic Resurfacing | 1 - 10 mJ | Full | 100 - 200 μm |
| Dermal Excision | 5 - 40 mJ | N/A | 0.2 mm x selected line 0.2 mm freehand |
What can you treat with CO2RE Intima?
Relieves signs of childbirth and aging
Restores vaginal tone, flexibility and shape
